Foco Two 1200 Slim

Deluxe refilling funnel for bioethanol fireplaces

Avoid spilling bioethanol when refilling the bio fire. This professional funnel for filling bioethanol is designed specific for bio fires.

Highlighted specifications

• Produced in stainless steel
• Big opening which minimizes waste
• Safe tool for filling your bioethanol fireplace

The funnel is simply placed into the burner, and then the filling of ethanol begins in the normal way. Indispensable tool for you who want a safe filling of the fireplace.

Did you know, that most of the accidents of bio fires happens under the filling? This is either because they are overfilled or poured on an open flame. Therefore, always use your common sense when filling the fireplace. Be sure to refill when the fireplace is cold. If you spill bioethanol, it is important that this is removed before lightning the fireplace.

Long lighter for bioethanol fireplace

Fireplace lighter to ignite your bio fireplace safely and comfortably. Avoid using the regular lighter where one can be in close contact with the flame by using this lighter.

What is more, it is recommended to use a long lighter since it is more comfortable to ignite with it. Additionally, it provides extra security so that the person who ignites is kept at a safe distance from the fire.

The lighter measures 17.5 cm and is thus particularly useful for igniting a fireplace. It can, with advantage, be used on other occasions and to ignite a candle.

NB: Ships without lighter gas.

Exterior frame for Foco One 1200 and Foco Two 1200 bioethanol fireplaces

The outer frame is mounted on the Foco 1200 inner frame and provides a frame around the built-in fireplace.

If you build your Foco One or Foco Two bio ethanol fire into an existing wall, it can be difficult to get a perfect finish around the frame. With this exterior frame, you can easily hide all imperfections and the grouting wont need to be perfect.

Theexterior frame is made from the same steel and with the same powder coating as the Foco built-in frame. The frame itself has a width of 5 cm all the way around and has a thickness of 4 mm.

Mounting of the outer frame

Assembly requires the following tools:

• Drill
• Metal Drill

Procedure:

1. Remove the safety glass and glass holders from the built-in frame
2. Slide the exterior frame into the inner frame.
3. The mounting holes in the bottom of the outer frame and the inner frame should now fit together.
4. Attach the glass holders through both the exterior and the inner frame.
5. At the top of the inner frame, drill two holes that match the holes in the outer frame.
6. Now screw the outer frame through the holes drilled in the built-in frame and also in the wall.

This exterior frame fits these Foco models:

• Foco One 1200 Slim
• Foco Two 1200 Slim
• Foco One 1200
• Foco Two 1200
